Field Surgical Support
Field Operating Table 05
Manual field operating table with an X-ray-translucent carbon-fibre platform and longitudinal slide.
Public product ID: NUP-MED-000541
Features
- Carbon-fibre transport case
- One-piece X-ray-translucent platform
- Longitudinal slide for imaging access
- Lightweight aluminium structure
- Gas-spring-assisted adjustment
- Antibacterial antistatic polyurethane mattress
Specifications
- Tabletop size (L × W): 1900 × 450 mm ±10 mm
- External size (L × W): 1900 × 500 mm ±10 mm
- Height: 600–800 mm ±10 mm
- Head section adjustment: Up 30° / down 50° ±5°
- Back section adjustment: Up 75° / down 20° ±5°
- Lateral tilt: Left 15° / right 15° ±5°
- Trendelenburg adjustment: Reverse 20° / standard 15° ±5°
- Leg section adjustment: Down 50° / outward 90° ±5°
- Horizontal slide: 200 mm ±10 mm
- Packed size (L × W × H): 800 × 600 × 600 mm ±10 mm
- Gross / net / case weight: 105 / 72 / 15.6 kg
Product details
- Tabletop size: 1900 × 450 mm ±10 mm
