Field Surgical Support
Field Operating Table 01
Manually adjusted foldable field operating table with gas-spring assistance and a transport case.
Public product ID: NUP-MED-000537
Features
- Manual operation without external power
- Foldable carbon-steel structure
- Gas-spring-assisted adjustment
- Detachable sections
- Lockable swivel casters
- Antibacterial polyurethane mattress
Specifications
- Tabletop size (L × W): 1960 × 490 mm ±10 mm
- External size (L × W): 1960 × 530 mm ±10 mm
- Height without mattress: 750–1050 mm ±10 mm
- Head section adjustment: Up 45° / down 70° ±5°
- Back section adjustment: Up 75° / down 18° ±5°
- Lateral tilt: Left 24° / right 24° ±5°
- Trendelenburg adjustment: Reverse 25° / standard 22° ±5°
- Leg section adjustment: Down 90° / outward 90° ±5°
- Kidney bridge elevation: 100 mm ±10 mm
- Packed size (L × W × H): 1200 × 900 × 725 mm ±10 mm
- Gross / net / case weight: 160 / 125 / 35 kg
Product details
- Tabletop size: 1960 × 490 mm ±10 mm
- Manual operation
