15 Inch Patient Monitor

Specifications

• Configuration: 15-inch non-touchscreen, 800 × 600 high resolution;
• Standerd parameters: SpO₂, ECG, PR, BP, Resp, Temp;
• Configuration: Standard electrocardiogram with 5-lead cable;
• Configuration: 2000mAh built-in battery;
• Configuration: Available in 8 languages, including Chinese and English
• Configuration: A set of adult accessories;
• Product weight: NW: 3.8 kg
• Product size: 305 × 160 × 287 mm
• ECG(Lead configuration): 6-pin, 5-lead ECG lead wires
• ECG (Gain): '25, '50，'100，'200
• ECG (Heart rate range Adults): 15 bpm to 300 bpm
• ECG(Newborns/children): 15 bpm to 350 bpm
• ECG (Electrode polarization voltage range): ± 300mV
• Respiration (Measurement method): RA-LL (R-F)Impedance Method
• Respiration (Respiration rate range: Adults): (0 -120) BrPM
• Respiration (Children and newborns): (0-150) BrPM
• Respiration (Apnea alarm): (10-40)seconds
• Measurement range of blood oxygen saturation: 0~100%, resolution:1%, accuracy:70%~100%:+2, 0%~69%
• Measurementrange of pulse rate: 20 bpm to 300 bpm, with a resolution of l bpm and an accuracy of ± 3 bpm
• Non-invasive blood pressure (Operating modes): manual/automatic/continuous
• Non-invasive blood pressure (Pulse Rate Range): (40-240) bpm
• Non-invasive blood pressure (Measurement range): Systolic pressure (40-270) mmHg, diastolic pressure (10-215) mmHg mean arterial pressure(20-235)mmHg
• Non-invasive blood pressure (Static pressure range.: (0-300)mmHg, static pressure accuracy:+3mmHg
• Body temperature , measurement Range: (0-50)℃, resolution: 0.1°c, accuracy
