12 Inch Patient Monitor 01

Specifications

• Configuration: 12.1-inch non-touchscreen, 800 × 600 high resolution;
• Standerd parameters: SpO₂, ECG, PR, BP, Resp, Temp;
• Configuration: Standard electrocardiogram with 5-lead cable ;
• Configuration: 2000mAh built-in battery;
• Configuration: Available in 8 languages, including Chinese and English
• Configuration: A set of adult accessories;
• Product weight: NW: 2.79 kg
• Product size: 340 × 245 × 134 mm
• ECG（Lead configuration）: 6-pin, 5-lead ECG lead wires
• ECG（Gain）: ´1.25，´2.5，´5.0，´10
• ECG（Heart rate range Adults: 1.0 bpm to 300 bpm
• ECG（Newborns/children）: 15 bpm to 350 bpm
• ECG（Electrode polarization voltage range）: ± 300mV
• Respiration（Measurement method）: RA-LL (R-F) Impedance Method
• Respiration（Respiration rate range: Adults）: (0 to 120) BrPM
• Respiration（Children and newborns）: (0-150) BrPM
• Respiration（Apnea alarm）: (10-40) seconds
• Measurement range of blood oxygen saturation: 0~100%, resolution: 1%, accuracy: 70%~100%: ± 2, 40% to 69%+3%
• Measurement range of pulse rate: 30 bpm to 300 bpm, with a resolution of l bpm and an accuracy of+3 bpm
• Non-invasive blood pressure (Operating modes): manual/automatic/continuous
• Non-invasive blood pressure (Pulse Rate Range): (40-240)bpm
• Non-invasive blood pressure (Measurement range): Systolic pressure (40-280)mmHg, diastolic pressure (10-220) mmHg mean arterial pressure(20-240) mmHg.
• Non-invasive blood pressure (Static pressure range): (0-300)mmHg, static pressure accuracy: +3mmHg.
• Dual-channel temperature measurement, measurement range: (0-50)°C, resolution: 0.1°c, accuracy
